Name: KQS-WSM Mini Integrated Weather Station with 5-in-1 Sensor IP64 Protection and Low Power Consumption
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KQS-WSM
Price: 5,000.00 USD
Availability: InStock

Домой > продукты > Environmental Monitoring >

KQS-WSM Mini Integrated Weather Station with 5-in-1 Sensor IP64 Protection and Low Power Consumption

Место происхождения:

Китай

Фирменное наименование:

KunQuan

Сертификация:

Номер модели:

KQS-WSM

Свяжитесь с нами

Запросите цитату

KQS-WSM Mini Integrated Weather Station with 5-in-1 Sensor IP64 Protection and Low Power Consumption

Подробная информация о продукции

Тип датчика:

Интегрированный 5-в-1 (ветер, температура, влажность, давление)

Масса:

240 г

Размеры:

Высота ~17 см, Макс. диаметр. ~10 см

Потребляемая мощность:

< 150 мВт Всего

Рейтинг защиты:

IP64

Коммуникация:

RS485/RS232/TTL (Modbus-RTU)

Условия оплаты и доставки

Количество мин заказа

1 шт.

Упаковывая детали

Каждый блок имеет отдельную коробку, и все коробки упакованы в стандартные пакеты или доступны клиен

Время доставки

5-8 рабочих дней

Условия оплаты

LC,D/A,D/P,T/T,Western Union,MoneyGram

Поставка способности

1000 шт/штук в неделю по договоренности

СОБЩЕННЫЕ ПРОДУКТЫ

KQS-ZSYT Fully Automatic Direct-Diffuse Integrated Radiation Monitoring Instrument with High Accuracy Dual Tracking Global Applicability and Multiple Communication Options

Лучшая цена

KQZ-GF Photovoltaic Weather Station with Meteorological-Grade Sensors, Fully Waterproof Design, and Customizable Mounting Pole

Лучшая цена

KQZ-BX Portable Weather Station with Fully Waterproof Design, Built-in Battery, and Foldable/Telescopic Structure

Лучшая цена

KQS-GTM Tubular Multi-layer Soil Moisture Monitoring Instrument with FDR Technology for Multi-layer Monitoring (10/20/30/40 cm) and Solar Power

Лучшая цена

Свяжитесь с нами

Свяжитесь сейчас

Описание продукта

KQS-WSM Mini Integrated Weather Station

KQS-WSM Mini Integrated Weather Station

The KQS-WSM mini integrated weather station is a compact, highly integrated environmental monitoring sensor. Compared with traditional all-in-one environmental sensors, it features a smaller design while maintaining powerful functionality. It can quickly and accurately measure five meteorological parameters: wind speed, wind direction, air temperature, humidity, and atmospheric pressure.

It is widely used for environmental monitoring in agriculture, meteorology, forestry, power systems, chemical plants, ports, railways, and highways.

Technical Parameters

Measurement Item (Optional)	Range	Accuracy	Resolution	Power Consumption
Wind speed	0-45 m/s	Start wind speed ≤ 0.8 m/s, ±(0.5 + 0.02V) m/s	0.1 m/s	40 mW
Wind direction	0-359°	±3°	1°	--
Air temperature	-40-80°C	±0.3°C	0.1°C	1 mW
Air humidity	0-100% RH	±5% RH	0.1% RH	--
Atmospheric pressure	300-1100 hPa	±0.5 hPa (25°C)	0.1 hPa	0.1 mW

Total sensor power consumption: <150 mW

Power supply: DC 5V / DC 9-30V / Others optional

Communication: RS485 (Modbus-RTU) / RS232 (Modbus-RTU) / TTL (Modbus-RTU)

Cable length: Standard 2 m

Weight: 240 g

Operating environment: 0-100% RH, -40°C to +60°C

Protection rating: IP64

Product Features

Integrated design enabling simultaneous monitoring of wind speed, wind direction, temperature, humidity, and atmospheric pressure
Measurement elements can be optionally configured as 2-parameter, 4-parameter, or 5-parameter combinations based on requirements
Compact and lightweight design: height approx. 17 cm, maximum diameter approx. 10 cm, weight under 0.25 kg, easy to install
Advanced filtering algorithm with special compensation for rain and fog conditions, ensuring stable and consistent data output
Each unit is calibrated before leaving the factory using wind tunnel and high/low temperature calibration chambers, ensuring compliance with national standards
Strong environmental adaptability, tested under high/low temperature, waterproof, and salt spray conditions

Dimensions
